Ludlow Tape M-Tak OS 7434B & 7435B Double-Sided Tape

    Quick ContactPrint
    Ludlow Tape M-Tak OS 7434B & 7435B Double-Sided Tape

    M-Tak Offset Double-Sided Tape

    Files

    Global

    Standardized Name
    Ludlow Tape M-Tak OS 7434B & 7435B Double-Sided Tape
    Berry Global EntityHHS Tape
    Products
    • Tapes & Adhesives
      • Industrial Tape
        • Packaging/Box/Envelope Tape
        • Specialty/Converter Tape
          • Mounting Tape
        Brands
        • HHS
          • Ludlow Tapes
          Markets
          • Shipping & Transportation
            • Delivery Services
              • Product Protection
                • E-Commerce
                  • Postal
                    • Warehousing
                    • Specialty Other
                      • Advertising Media
                      Capabilities
                      • Manufacturing
                        • Tapes Manufacturing
                          • Adhesive Coating
                            • Finger-Lift Edge™ Technology
                          Country Serviced / Available In
                          • Global
                            Features / Benefits

                            Synthetic Rubber Adhesive

                            • High adhesion for a secure permanentbond to plastics, papers and mailers
                            • Strong initial tack

                            PET Film Carrier

                            • Provides support and structure for added stability
                            • Conformable

                            Offset Finger-Lift Edge

                            • Easy to start, easy to use
                            • Extra-wide offset edge for easy removal
                            End Use / Recommended Applications
                            Medium to heavy corrugated mailer sealing for high stress shipping applications.

                            Spec

                            + Global

                            Berry Catalog SKU
                            M-Tak OS 7434B & 7435B
                            Sample Request AvailableNo

                            + Physical Properties

                            Product ConstructionDouble-Coated Tape
                            Color(s)Clear

                            + Packaging Data

                            Max Temp Range<176 °F

                            + Non-Packaging Data

                            Gauge / Mil
                            12.9 mil
                            Gauge/Thickness Range9.1 mils to 13.0 mils
                            Carrier / Support / FacestockPET (Polyester) Film
                            Adhesive TypeRubber
                            Air-Side Adhesive Thickness (mil)
                            4.4 mil
                            Adhesive Type (Liner Side)Rubber
                            Liner Side Adhesive Thickness (mil)
                            4.4 mil
                            Liner TypePaper
                            Peel Strength / Adhesion to Steel
                            160 oz/in
                            Peel Strength / Adhesion to Steel (Liner Side)
                            165 oz/in
                            Operating Temp Range
                            -20 to 170 °F

                            + CPNA

                            Adhesive
                            Synthetic Rubber
                            Application
                            Medium to heavy corrugated mailer sealing for high stress shipping applications.
                            Brand
                            Ludlow Tape
                            Carrier
                            0.5 mil PET Film
                            Construction
                            Double Coated
                            Features
                            Thick adhesive on both sides provides exceptional bond strength to corrugated mailer materials. High tack, tamper evident upon removal. Strong and conformable. Extra-wide offset edge for fast application and sealing.
                            Liner
                            54# SCK
