Adchem GTB/GTW 192 Foam Glazing Tape

    Quick ContactPrint
    Adchem GTB/GTW 192 Foam Glazing Tape

    Adchem GTB/GTW 192 Foam Glazing Tape provides an excellent quick stick when used for applications such as providing cushioning to absorb vibration and shock.

    Files

    Global

    Standardized Name
    Adchem GTB/GTW 192 Foam Glazing Tape
    Berry Global EntityHHS Tape
    Products
    • Tapes & Adhesives
      • Construction Tape
        • Glazing & Muntin Tape
        • Specialty/Converter Tape
          • Appliance Tape
            • Gasket Sealing Tape
              • Sound & Vibration Damping Tape
            Brands
            • HHS
              • Adchem
              Brand URL
              http://adchem.com/main/home.aspx
              Markets
              • Building & Construction
                • Commercial Construction
                  • Prefabricated & Temporary Structures
                    • Residential Construction
                    • Specialty Other
                      • Acoustics
                      Capabilities
                      • Manufacturing
                        • Tapes Manufacturing
                          • Adhesive Coating
                            • Adhesive Formulation/Mixing
                          Country Serviced / Available In
                          • Global
                            Features / Benefits

                            Acrylic Adhesive

                            • Excellent quick stick
                            • Moderate shear strength
                            • Good UV resistance

                            Foam Carrier

                            • Conformable
                            • Minimal moisture absorption

                            PE Film Liner

                            • Lends itself to die-cutting and kiss cuts
                            End Use / Recommended Applications
                            Seal window glass onto wood, aluminum, or plastic frames. Provides cushioning to absorb vibration and shock. Seals against air, moisture, light and dust. Thermal insulating and sound deadening.

                            Spec

                            + Global

                            Berry Catalog SKU
                            GTB/GTW 192
                            Sample Request AvailableNo

                            + Physical Properties

                            Product ConstructionDouble-Coated Tape
                            Color(s)White. Black

                            + Packaging Data

                            Max Temp Range212-257 °F

                            + Non-Packaging Data

                            OEM / Specification Body & Specification
                            • AAMA
                              • 810.1-16
                              Gauge / Mil
                              39.25 mil
                              Gauge/Thickness Range>13.0 mils
                              Carrier / Support / FacestockFoam
                              Carrier Thickness (mil)
                              31.25 mil
                              Adhesive TypeAcrylic
                              Air-Side Adhesive Thickness (mil)
                              2.0 mil
                              Adhesive Type (Liner Side)Acrylic
                              Liner Side Adhesive Thickness (mil)
                              2.0 mil
                              Liner TypeFilm
                              Operating Temp Range
                              -30 to 220 °F

                              + CPNA

                              Application
                              Seal window glass onto wood, aluminum, or plastic frames. Provides cushioning to absorb vibration and shock. Seal against air, moisture, and vapor. Thermal insulation and sound deadening.
                              Brand
                              Adchem
                              Carrier
                              PE Foam
                              Carrier Thickness
                              1/32in
                              Construction
                              Double Coated
                              Features
                              Excellent quick stick and moderate shear strength. Good UV resistance. Meets AAMA 810.1-16 for expanded cellular glazing tapes.
                              Laminating Adhesive Description
                              Acrylic
                              Laminating Thickness
                              2.0 mil
                              Liner
                              Polypropylene
                              Liner Thickness
                              2.0 mil

                              See also

                              Adchem 156M Double-Coated PET Film Tape

                              Adchem 156M Double-Coated PET Film Tape provides conformability when used for applications such as bonding and laminating to a wide variety of cloths, vinyls, corks, paper, rigid and flexible plastics. For mounting displays, signs, posters, mirrors, nameplates, and decorative wall products. Especially suited for splicing various types of paper products. Applications where resistance to ultra-violet light and excellent performance during temperature extremes is required. The 256M also exhibits resistance to some plasticizers.

                              Adchem EBTB Double-Coated Tape

                              A 1/32" thick black, 6 lb. density cross linked polyethylene foam coated on both sides with a high performance acrylic adhesive system developed specifically for extreme environmental exposures that does not require silane/isopropanol pre-treatment for adhesion to glass or ceramic surfaces. Provide for long-term indoor and outdoor bonding of glass, ceramics, primed, painted, aluminum and plastic surfaces without silane/isopropanol pre- wash. The double-coated tape was engineered specifically for resistance to air, water, detergents, moisture, light and dust penetration. Foam is also used to fill any irregularities and functionally provide cushioning, absorb vibration and shock, and allow for expansion and contraction due to temperature variations. See associated sheets for specific testing and performance data.
