Adchem MTB Double-Coated Tape

    Quick ContactPrint
    Adchem MTB Double-Coated Tape

    A 1/16" thick black, 4 lb. density cross linked polyethylene foam coated on both sides with a high performance acrylic adhesive system developed specifically for extreme environmental exposures that does not require silane/isopropanol pre-treatment for adhesion to glass or ceramic surfaces. Provide for long-term indoor and outdoor bonding of glass, ceramics, primed, painted, aluminum and plastic surfaces without silane/isopropanol pre- wash. The double-coated tape was engineered specifically for resistance to air, water, detergents, moisture, light and dust penetration. Foam is also used to fill any irregularities and functionally provide cushioning, absorb vibration and shock, and allow for expansion and contraction due to temperature variations. See associated sheets for specific testing and performance data.

    Files

    Global

    Standardized Name
    Adchem MTB Double-Coated Tape
    Berry Global EntityHHS Tape
    Products
    • Tapes & Adhesives
      • Specialty/Converter Tape
        • Graphics & Graphics Protection Tape
      Brands
      • HHS
        • Adchem
        Brand URL
        http://adchem.com
        Markets
        • Specialty Other
          • Advertising Media
            • Custom Converting
            Capabilities
            • Manufacturing
              • Tapes Manufacturing
                • Adhesive Coating
              Country Serviced / Available In
              • Global
                Features / Benefits
                • Acrylic Adhesive
                • Designed for extreme environmental exposure
                • Moderate shear strength
                • Excellent UV resistance
                • Excellent adhesion to glass
                • No pre-wash required
                • Foam Carrier
                • Conformable and allows for expansion and contraction with temperature variations
                • Resistant to air, water, and detergents
                •  74# Polycoated Kraft Liner
                • Conformable and good dimensional stability



                End Use / Recommended Applications
                Provide for long-term indoor and outdoor bonding of glass, ceramics, primed, painted, aluminum and plastic surfaces without silane/isopropanol pre- wash. The double-coated tape was engineered specifically for resistance to air, water, detergents, moisture, light and dust penetration. Foam is also used to fill any irregularities and functionally provide cushioning, absorb vibration and shock, and allow for expansion and contraction due to temperature variations.

                Spec

                + Global

                Berry Catalog SKU
                MTB
                Sample Request AvailableNo

                + Physical Properties

                Product ConstructionDouble-Coated Tape
                Color(s)Black
                MaterialRubber

                + Packaging Data

                Max Temp Range212-257 °F

                + Non-Packaging Data

                Gauge / Mil
                72
                Carrier / Support / FacestockFoam
                Carrier Thickness (mil)
                62.5 mils
                Adhesive TypeAcrylic
                Air-Side Adhesive Thickness (mil)
                2.0
                Adhesive Type (Liner Side)Acrylic
                Liner Side Adhesive Thickness (mil)
                2.0
                Liner TypeCoated Kraft Paper
                Operating Temp Range
                -30 to 220 °F
                Laminating Substrate
                • Polyurethane-Ester Foam

                  + CPNA

                  Adhesive
                  Acrylic
                  Application
                  Provide for long-term indoor and outdoor bonding of glass, ceramics, primed, painted, aluminum and plastic surfaces without silane/isopropanol pre- wash. The double-coated tape was engineered specifically for resistance to air, water, detergents, moisture, light and dust penetration. Foam is also used to fill any irregularities and functionally provide cushioning, absorb vibration and shock, and allow for expansion and contraction due to temperature variations.
                  Brand
                  Adchem
                  Carrier
                  1/16" PE Foam
                  Construction
                  Double Coated
                  Features
                  Acrylic Adhesive - Designed for extreme environmental exposure, Moderate shear strength, Excellent UV resistance, Excellent adhesion to glass, No pre-wash required Foam Carrier - Conformable and allows for expansion and contraction with temperature variations, Resistant to air, water, and detergents. 74# Polycoated Kraft Liner - Conformable and good dimensional stability.
                  Laminating Adhesive Description
                  Acrylic
                  Liner
                  74 # PC KFT
