Description

- Ultrasonic sealing system with electronic self-calibration
- High-end Standard 6 sealing system
- Easy accessibility and tool-free disassembly of strap way components
- Wear-free DC drives with integrated electronics
- Stepless turnable operation panel for many-sided operation
- Adjustable strap tension via potentiometer
- Switching from maximum to material-friendly Eco-speed in the control
- Quick strap coil change
- Strap coil changeable from the front and the side
- Automatic strap threading system
- Strap end detection with ejection of remaining strap
- Automatic strap loop ejection
- Extremely low energy consumption
- 4 castors, 2 of them lockable
- CE marking inclusive conformity declaration
- Soft strapping selectable for sensitive packages
- Machine completely corrosion-free (use of stainless steel or corrosion-free materials, for example V2A, V4A aluminum)
- IP 56 protection class design
- Sensitive components (e.g. motors) are equipped with additional covers

Variants & Options

- Cost-efficient, pneumatic hold-down device
- Table extension
- Automatic adjustment of the strap tension by package height detection
- Balls or rollers in the table plate
- Lowering chassis H = 730 mm – 835 mm
- Manual strapping release via additional fixed or flexible foot pedal
- Automatic strapping release via light sensor
- Strap end detection with signal in the control panel
- Parameter control panel for setting strapping Parameters
- 4 castors
- Signal light
- Signal exchange via 16-pole contact

Technical details

Capacity: up to 50 cycles / min. using 5 mm strap

Straps: PP straps: 5, 6, 8, 9, 10 or 12 mm

Strap coil dispenser:
Core diameter: 200 mm
Core width: 190 mm
max. outer diameter: 430 mm

Electricity:
Voltage: 230 V, 50/60 Hz, 1 PH, Schuko plug
Power consumption: approx. 0.2 kW

Sealing unit: Standard 6 unit

Weight: 200 kg

Frame sizes:
600 x 600 mm
